Series 8 Downdraft hood 80 cm Clear glass, Black
DDW88MM60B

1 / 0
Photo Nr. 1 of the product DDW88MM60B
Photo Nr. 2 of the product DDW88MM60B
Photo Nr. 3 of the product DDW88MM60B
Photo Nr. 4 of the product DDW88MM60B
Photo Nr. 5 of the product DDW88MM60B
Photo Nr. 6 of the product DDW88MM60B
Photo Nr. 7 of the product DDW88MM60B
Photo Nr. 8 of the product DDW88MM60B
Photo Nr. 9 of the product DDW88MM60B
Photo Nr. 10 of the product DDW88MM60B
Photo Nr. 11 of the product DDW88MM60B
Photo Nr. 12 of the product DDW88MM60B
Photo Nr. 13 of the product DDW88MM60B
Photo Nr. 14 of the product DDW88MM60B
Photo Nr. 15 of the product DDW88MM60B
Photo Nr. 16 of the product DDW88MM60B
Photo Nr. 17 of the product DDW88MM60B

Series 8 Downdraft hood 80 cm Clear glass, Black
DDW88MM60B

Energy efficiency class A from D to A+++
Find a local Dealer
Find a local dealer in your vicinity

Series 8 Downdraft hood 80 cm Clear glass, Black
DDW88MM60B

Energy efficiency class A from D to A+++
Find a local Dealer
Find a local dealer in your vicinity

Technical Overview

Installation typology
Built-in
Width
80 cm
Control your hood with your Home Connect hob
Yes
Noise level
62 dB(A) re 1 pW
PrefectAir Sensor
Yes
Operating Mode
Convertible
Max. air extraction
501 m³/h
Boost position air extraction
775 m³/h

Highlights

Awards

Visual badge of the award

Specifications

Width
80 cm
Colour
Black
Installation typology
Built-in
Operating Mode
Convertible
Total power of the motors
300 W
Type of control setting devices
touch control,
Number of speed settings
3-stage + 2 intensive
Max. air extraction
501 m³/h
Boost position air extraction
775 m³/h
Sound power at max. speed (2010/30/EC)
62 dB
Sound power boost (2010/30/EC)
70 dB
Max. air recirculation
416 m³/h
Boost position output recirculating
525 m³/h
Sound power at max. speed (recirculation)
65 dB
Sound power boost (recirculation)
70 dB
Grease filter material
Washable stainless steel
Energy efficiency rating
A
Total annual energy consumption
36.9 kWh/annum
Included user manuals
[AR, EN]
Voltage
220-240 V
Height of the appliance
709 mm
Width of the appliance
802 mm
Depth
140 mm
Dimensions of the packed product (HxWxD)
620x1330x870 mm
Height of the chimney
GENERAL.N_A mm
Diameter of air outlet
150 mm
No-return airflow flap
No
Length electrical supply cord
130 cm
Net weight
37.5 kg
Handle bar
Not applicable
Appliance height exhaust air max
959 mm
Appliance height exhaust air min
709 mm
Appliance height recirculating max
959 mm
Appliance height recirculating min
709 mm
Maximum width for installation
781 mm
Minimum width for installation
781 mm
Depth for installation
123 mm
1 / 0
Photo Nr. 1 of the product
Photo Nr. 2 of the product
Photo Nr. 3 of the product
Photo Nr. 4 of the product
Photo Nr. 5 of the product
Photo Nr. 6 of the product
Photo Nr. 7 of the product
Photo Nr. 8 of the product
Photo Nr. 9 of the product
Photo Nr. 10 of the product
PrefectAir Sensor
Yes
SilentPowerDrive - efficient and extra silent
Yes
Silence
No
Clean filter reminders
Yes
Boost position
Yes
Delay Shut off modes
Yes
Remote control
No
Type of lamps used
None
Total power of the lamps
GENERAL.N_A W
Colour temperature
Not applicable
Illumination type softlight
No
Color temperature control via smartphone with Home Connect
No
emotionLight Pro
No
Home ConnectFootnote 1: Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com.
Yes
Home Connect Features
Remote Monitoring and Control
Control your hood with your Home Connect hob
Yes
Smart Hood Automatic
No
